BL-37

WASH

The BL-37 Wash is a high output wash light with a RGBW LED system. With a zoom range of 10° - 60° plus fast, smooth and quiet movement it is able to be used for a wide array of applications and venues now all sizes.


PRODUCT PERFORMANCE

The BL-37 Wash is a high output wash light with a 4 in 1 RGBW LED system. With a Zoom range of 10° - 60° it is able to be used for a wide array of applications and venues of the largest sizes.

PRODUCT SPECS

OPTICAL

  • Source: 37 x 25 watt RGBW LEDs (flicker free)
  • Color temperature: 2700-6500k
  • Zoom range: 10°-60° linear zoom
  • Minimum LED Lifespan: 30,000 hours

DYNAMIC EFFECTS

  • Pan: 540 (16 bit)
  • Tilt: 270 (16 bit)
  • Dimming: 0-100% linear dimming
  • Strobe: Variable
  • Zoom: 10°-60° linear zoom
  • Color mixing: Infinite color mixing (RGBW)

CONTROL/CONNECTIONS

  • DMX
  • RDM
  • Control Modes: 10 channel / 15 channel / 21 channel / 37 channel / 39 channel
  • Data in/out: 5 pin DMX
  • Power input/output: True 1

ELECTRICAL

  • Input range (AC 100-240v 50/60Hz)
  • Max consumption: 850 watts

COOLING

  • Quiet cooling system with variable fans

PHYSICAL

  • Weight: 38lbs (17.24kg)
  • Dimensions: 16.2” x 12.6” x 18.3” (412mm x 321mm x 465mm)
